0.45um-100um Filtration Accuracy Titanium Metal Foam Suppliers

  • Brand:

    ZOPIN
  • Item NO.:

    ZP-TiF14
  • Payment:

    L/C, D/A, D/P, T/T, Western Union, PayPal, credit card, Alipay, etc
  • Lead Time:

    In stock
  • WhatsApp:

    +86 18832681205
  • Wechat:

    18832681205
  • Email:

    Daisy@foam-material.com
  • Product Detail


0.45um-100um Filtration Accuracy Titanium Metal Foam Suppliers



Introduction

With its unique properties, titanium foam can be widely used in the pharmaceutical industry, water treatment industry, food industry, bioengineering, chemical industry, petrochemical, metallurgical industry, and gas purification. It is a new material with broad development prospects.

1. In the infusion of the pharmaceutical industry, small injections, eye drops, decarbonization filtration in the concentration of oral liquids, and security filtration before terminal filtration in the lean distribution.

2. Removal of impurities in the production process of raw materials, decarbonization filtration, and fine filtration of materials.

3. Security filtration of ultrafiltration, RO, EDI systems in the water treatment industry, filtration after ozone sterilization, and ozone aeration.

4. Clarification and filtration of beverages, white sprinkles, beer, vegetable oil, mineral water, soy sauce, and vinegar in food and beverage.

5. Decarbonization filtration and precision filtration of liquid products, liquid raw materials and pharmaceutical intermediates in the chemical industry, ultrafine fine bodies, catalyst recovery, precision filtration after resin adsorption, system heat transfer oil, material removal, and impurity filtration, catalytic gas Purification and so on.

6. Oilfield backflow water filtration, security filtration before reverse osmosis in the desalination field.

7. High-temperature decarbonization and de-whitening filtration in the dye industry.

8. Filtration of steam, compressed air


Specification

Filtration accuracy

0.45um-100um

Porosity

28-50%

Transmittance rate

0.02-20M3cm/m2h.mmH2O

Compressive strength

0.5-1.5Mpa

Temperature resistance

280 ° C (wet state)

Maximum working pressure range

0.6Mpa

Precision

0.22 µm 0.45 µm 1 µm 3 µm 5 µm 10 µm 20 µm 30µm  50 µm 80 µm 100 µm


Reference dimensions

0.7mm*200mm*300mm

0.8mm*200mm*300mm

0.9mm*200mm*300mm

1.0mm*200mm*300mm

1.1mm*200mm*300mm

1.2mm*200mm*300mm

1.3mm*200mm*300mm

1.4mm*200mm*300mm

1.5mm*200mm*300mm

1.6mm*200mm*300mm

1.7mm*20mm*300mm

1.8mm*200mm*300mm

1.9mm*200mm*300mm

2 to 3mm*200mm*300mm

The size can be customized
