99.9% Pure 40 Mesh 100/05 Woven Copper Wire Mesh Cu Metal Netting

Introduction

Phosphor copper woven mesh is crafted from a copper alloy that contains a higher proportion of phosphorus. This mesh exhibits excellent resistance to corrosion, making it a preferred choice in environments prone to chemical exposure or where corrosion resistance is crucial. Phosphor copper woven mesh finds extensive applications in industries requiring filtration, separation, and screening due to its durability and resistance to harsh conditions.

Specification

Material	Phosphorus copper wire
Craft	Plain weave, Twill weave, Embossing
Mesh count	1 - 500 mesh (Due to limited drawing technology, the highest mesh count for brass and purple copper mesh is currently up to 200 mesh, while phosphorus copper mesh can be produced from 1-500 mesh)
Wire diameter	0.03-5mm
Aperture	0.029-50mm
Width	0.914, 1, 1.2, 1.3, 1.5, 1.8, 2, 2.5 (Can be processed into narrower widths down to 3mm upon customer request)
Length	Generally 30m for stock, but production can be extended based on customer requirements, up to 180m
Applications	Phosphorus copper mesh has versatile applications in industries such as mining, metallurgy, construction, and pharmaceuticals for sieving purposes.
